24CUG / 24CUH
24CUG
- Condenser Motor
- Resonance - Noise - Absorption Structure
- High Performance Sirocco Fan
- HP (half pitch) motor with ball bearings
- Taper blade sirocco fan
- Curve-shaped backdraft shutter
- Super low noise level
As low as $170.00
Out of stock
SKU
24CUG
- Reverse flow prevention shutter is installed on the side of the adapter.
- Seam-processed casing
- Long-life Motor
- High performance sirocco fan
- Square to round adapter equipped with nail
- Cassette type discharge opening
- Pre-painted colour steel casing
- One-touch louver
*All prices include 8% GST, exclude delivery and installation.
24CUG
Model | Voltage | Hz | Watt | R.P.M | Air Volume | Noise | Weight | Installation Space |
CMH (CFM) | dB(A) | (kg | (mm) | |||||
24CUF | 220 | 50 | 14 | 690 | 140 (82) | 28 | 2.9 | 240 x 240 |
220 | 60 | 16 | 690 | 140 (82) | 29 | 2.9 | 240 x 240 |

- Super low noise design
- Long life ball bearing motor
- Taper blade sirocco fan
- Double chamber design
- Pre-installed power cord
