24CDG / 24CDH
24CDG
- Condenser Motor
- Resonance - Noise - Absorption Structure
- High Performance Sirocco Fan
- HP (half pitch) motor with ball bearings
- Taper blade sirocco fan
- Curve-shaped backdraft shutter
- Super low noise level
As low as $210.00
In stock
SKU
24CDG
- Reverse flow prevention shutter is installed on the side of the adapter.
- Seam-processed casing
- Long-life Motor
- High performance sirocco fan
- Square to round adapter equipped with nail
- Cassette type discharge opening
- Pre-painted colour steel casing
- One-touch louver
*All prices include 8% GST, exclude delivery and installation.
24CDG
| Model | Voltage | Hz | Watt | R.P.M | Air Volume | Noise | Weight | Installation Space |
| CMH (CFM) | dB(A) | (kg | (mm) | |||||
| 24CDF | 220 | 50 | 17 | 790 | 170 (100) | 31 | 3.0 | 240 x 240 |
| 220 | 60 | 19 | 805 | 170 (100) | 33 | 3.0 | 240 x 240 |
- Super low noise design
- Long life ball bearing motor
- Taper blade sirocco fan
- Double chamber design
- Pre-installed power cord
